Steel Frame 80-300 C U Purlin Cold Metal Roll Forming Machine Lowest Price
Main Parameters:
| 1 | Coil width | 100-400mm |
| 2 | Cover width | 80-300mm |
| 3 | Coil sheet thickness | 1.5--3.0mm |
| 4 | Material of frame | 400H steel |
| 5 | Diameter of shaft (solid shaft) | (high grade) 45# Steel |
| 6 | Diameter of shaft (solid shaft) | 80mm |
| 7 | Treatment of roller | quenched and tempered treatment, hard chromized coated 0.05-0.07mm |
| 8 | Thickness of middle plate | 20mm |
| 9 | Forming station | 15 stations |
| 10 | Drive type of roll forming machine | drive by chain(0.8 inch) |
| 11 | Power of main motor | 11KW |
| 12 | Motor power of hydraulic station | 4KW |
| 13 | Oil pump of hydraulic station | No.46 gear oil pump (high grade) |
| 14 | Forming speed | about 8-10 m/min |
| 15 | Voltage | 380V/50Hz/3phase |
| 16 | Hydraulic cutting | cutting controlled by PLC |
| 17 | Accuracy of cutting | +/- 1mm |
| 18 | Razor blades material | Cr12, quenching 58-62 ° |
| 19 | Electrically controlled system | entire machine controlled by PLC |
| 20 | PLC | DELTA(TAIWAN) |
| 21 | Weight of main forming machine | About 3.2 T |
Working flow:
Our service:
1.Technology :We have technical centers and innovative designing teams for different kinds of production lines.
2.After Sale Service :Warranty period 1 year , after this period , we are willing to give help if customer needs accessory . The real cooperation will not end at the delivery . we believe that satisfied after sale service means a lot.
3.Inspected by the Sellers :After completing the manufacturing and assembling of the equipments, we will test the machines and commissioning in the workshop.
4.Inspected by the Buyers: After confirmation of a sound work of the line, we will invite our customer to send their representatives to inspect the production lines in our factories.
Packing and Loading:
Standard Export Packing.
1.One 40ft container for loading one set machine with manual decoiler;
2. The whole Wiped Anti Rust Oil, PLC controller covered by foam film;
3. Spare parts and some small parts packed in plastic tooling box;
4. All Components Fixed by steel wire with Container.
Machine photos:
company:
Cangzhou Best Machinery Manufacturing co., LTD is specialized in the manufacture of high-end equipment cold bending forming equipment manufacturer,has a professional engineer for technical guidance.Engineers engaged in cold bending mechanical equipment design for more than 20 years,has a wealth of design concept.Can provide users with a special type of design and manufacture.At the same time to sell equipment for installation,guidance,production,commissioning one-stop service.
Contact me:
If you need more details, please inquiry me, will send you lowest price and machine video.
